Rosemount 2051L Level Transmitter

Product Description

Gain confidence with the reliable performance of the Rosemount 2051L Level Transmitter, a transmitter that provides level measurements with a variety of process connections, materials and output protocols. This transmitter is safety certified, and allows for Tuned-System™ Level assembly and direct mounting. Engineered with a Local Operator Interface (LOI), this device offers easy, on-site commissioning.

Specifications

* Max. Operating Pressure: Up to 300 psi (20,68 bar)

* Process Temperature Range: Based on fill fluid - Maximum 401°F (205°C), Minimum -157°F (-105°C)

* Communication Protocol: 4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS®, 1-5 V Low Power HART®

* Seal System Type: Direct Mount, Tuned-System

* Transmitter Connection: Welded-Repairable

* Process Connection:

                                     Flanged: ANSI/ASME, EN/DIN, JIS

* Process Wetted Material: 316L SST, Alloy C-276, Tantalum

* Diagnostics: Basic Diagnostics

* Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE®, hazardous location, see full specs for complete list of certifications

Features

• Designed with a variety of process connections, materials and output protocols to meet diverse application requirements

• Tuned-System Level assembly and direct mounting produce optimal performance for level applications

• SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations

• Local Operator Interface (LOI) for simple, local commissioning on-site without the use of extra tools or training

• Optimized seal system construction ensures a quality measurement in harsh process conditions
