TEST GAUGE SCHMIERER MODEL FU250

Basic design:

V 004 Ranges...

Accuracy: 0, 6% or 0,25% fsd

White dial, black lettering

Pointer deflection 270°

Pointer centric

Bourdon-tube: st. steel 316L

Precision movement made from stainless steel

V 020 Safety glass

V 022 Blow-out disc

Bottom connection,

V064 Connection: 1/2” BSP (m)

Case: st. steel 304

Bezel: st. steel 304

Variations: see back side

Variations:

V 012 Works test certificate acc. EN10204-3.1

V 014 DAkkS calibration certificate

V 027 Bezel and case polished

V 032 Red marking at...

V 034 Customer logo

V 040 Special graduation

V 065 Special thread

V 069 Drag pointer on window

V 080 Front flange for panel mounting

V 081 Back flange for wall mounting

V 084 Back connection, eccentric

Z 521 Throttle screw

Additional variations: on request
