ĐỒNG HỒ ĐO ÁP SUẤT DẠNG CAPSULE SCHMIERER MODEL KU160

Basic design:

V 004 Ranges...

Accuracy: 1,6 % fsd

White dial, black lettering

Pointer deflection 270°

Pointer centric

Capsule: st. steel 316Ti

V 020 Safety glass

V 022 Blow-out disc

V 050 Movement: st. steel

Bottom connection

V 064 Connection: 1/2” BSP(m)

V 085 Case: st. steel 304

Bayonet lock bezel: st. steel 304

Variations: see back side

Variations:

V 027 Bezel and case polished

V 032 Red marking at...

V 034 Customer logo

V 036 Mark pointer on dial

V 038 Fine graduation

V 040 Special graduation

V 065 Special thread

V 068 Adjustable pointer

V 080 Front flange for panel mounting

V 081 Back flange for wall mounting

V 082 Triangular rim bezel with fixing bracket

V 084 Back connection eccentric

Z 521 Throttle screw

Additional variation: on request
