ĐỒNG HỒ ĐO ÁP SUẤT DẠNG MÀNG SCHMIERER MODEL PAKU100

Basic design:

V 004 Ranges...

Accuracy: 1,6 % fsd

White dial, black lettering

Pointer deflection 270°

Pointer centric

Diaphragm: Duratherm 600

Bellow: st. steel 316Ti

V 020 Safety Glass

V 022 Blow-out disc

V 050 Movement made from st.steel bottom connection

V 064 Connection: 1/2” BSP(m)

V 085 Case: st. steel 304

Bayonet lock bezel: st. steel 304

Variations: see back side

Variations:

V 027 Bezel and case polished / PTFE coated

V 032 Red marking at...

V 034 Customer logo

V 036 Mark pointer on dial

V 038 Fine graduation

V 040 Special graduation

V 052 Measuring element and connection for special applications

V 060 Overload safety, see table – Link

V 065 Special thread

V 069 Drag pointer on window

V 075 Manodamp® Movement with damped axle

V 090 Solid-front case, blow-out back

V 095 Glycerin filling

V 096 Insulating oil filling

V 119 Junction box

V 125 Bayonet lock bezel for variations

V 136 Contact device

Possible connections list – Link

V 141 Add-on transmitter

V 142 Built-in potentiometric transmitter

Z 521 Throttle screw

Additional variations: on request
