ĐỒNG HỒ ĐO ÁP SUẤT SCHMIERER MODEL RU100

Basic design:

V 004 Ranges...

Accuracy: 1,0 % fsd

White dial, black lettering

Pointer deflection 270°

Pointer centric

Bourdon-tube: 316 L st. steel

Socket: 316 L st. steel

V 020 Safety Glass

V 022 Blow-out disc

V 050 Movement: st. steel Bottom connection

V 064 Connection: 1/2” BSP (m)

V 085 Case : st. steel 304

Bayonet lock bezel: st. steel 304

Variations: see back side

Variations:

V 027 Bezel and case polished / PTFE coated

V 032 Red marking at...

V 034 Customer logo

V 036 Mark pointer on dial

V 038 Fine graduation

V 040 Special graduation

V 065 Special thread

V 069 Drag pointer on window

V 075 Manodamp® Movement with damped axle

V 080 Front flange for panel mounting

V 081 Back flange for wall mounting

V 082 Triangular rim bezel with fixing bracket

V 084 Back connection eccentric

V 090 Solid front case, blow out back

V 095 Glycerine filling

V 096 Insulating oil filling

V 119 Junction box

Diaphragm seals – Link

Possible connections – Link

V 125 Bayonet lock bezel for variations

V 136 Contact device

V 141 Add-on transmitter

V 142 Built-in potentiometric transmitter

V 144 Transmitter, integrated (max. 40 bar)

V 200 Filling for diaphragm seal

Z 521 Throttle screw

Additional variations: on request
