ĐỒNG HỒ ĐO ÁP SUẤT SCHMIERER MODEL RU63

Basic design:

V 004 Ranges...

Accuracy: 1,6 % fsd

White dial, black lettering

Pointer deflection 270°

Pointer centric

Bourdon-tube: 316L

Socket: 316L

V 020 Safety Glass

V 050 Movement: stainless steel Bottom connection

Connection: 1/4” BSP(m)

Case: 304 st.steel

Bayonet lock bezel: 304 st.steel

Variations: see back side

Variations:

V 032 Red marking at...

V 040 Special graduation

V 065 Special thread (adaptor)

V 080 Front flange for panel mounting

V 081 Back flange for wall mounting

V 082 Triangular rim bezel with fixing bracket

V 084 Back connection, centric

V 095 Glycerine filling

Z 521 Throttle screw

Additional variations: on request
