Nominal diameter: 100 and 160 mm
Accuracy: ±1.0% of full scale
Scale range (MPa, kPa, bar):
0 ~ 10% square root scale
0 ~ 100% linear scale
Working temperature:
Ambient: -40 ~ 65°C
Fluid: Max. 200°C
Working pressure:
Steady: 75% of full scale
Over range protection: 130% of full scale
Degree of protection: EN60529/IEC529/IP65
Temperature effect: Accuracy at temperature above and below the reference temperature (20℃) will be effected by approximately ±0.4% per 10℃ of full scale
Pressure connection: Stainless steel (316SS)
Element:
Stainless steel (316SS)
C type bourdon tube
Case: Stainless steel (304SS)
Cover: Stainless steel (304SS)
Window: Safety glass
Movement: Stainless steel
Dial: White aluminium with black graduations
Pointer: Black painted aluminium alloy
Process connection:
1/4¼", 3/8", 1/2" PT, NPT and PF
1/4" PT(F), 1/4" NPT(F)
Process input: 0.02 ~ 0.1 Mpa
