Applications
* For pressure measurement in gaseous and liquid, also aggressive media for demanding high purity applications, also in aggressive ambience
* Semiconductor and flat panel industry
* Gas distribution systems
* Medical gases
* Hook-up-application
Special Features
* Dead space free media chamber
* Excellent rinsing behaviour
* Helium leak tested, leak rate ≤ 10-9mbar · l/s
* Case and media chamber electropolished, surface roughness Ra ≤ 0.25 μm
* All ultra high purity gas fittings available
Description
Nominal size: 2"
Accuracy class:
Grade B according to ASME B40.1
Higher accuracy class on request
Scale ranges:
-1 . 4 bar / -30 inHg ... 60 psi
-1 . 9 bar / -30 inHg ... 130 psi
Operating temperature:
Ambient: -10 ... + 60 °C
Medium: +60 °C maximum
Pressure connection: All ultra high purity gas fittings available
Pressure element: Inconel
Dial: Aluminium, white, black/red lettering, dual scale bar/psi
Pointer: Aluminium, black
Case: Stainless steel 316L, electropolished
Window: Polycarbonate, twist-lock
