ZXF8030 Explosion Proof Corrosion Resistance Control Units

Application

* Designed for explosive atmospheres Zone 1 and Zone 2

* Designed for combustible dust Zone 21 and Zone 22

* Designed for IIA, IIB and IIC groups explosive atmospheres; Designed for temperature classifications T1~T6

* Designed for explosive hazardous locations such as oil refinery, storage, chemical, pharmaceuticals, military industries, etc

* Designed for the electrical control system for the users with function of sending order and monitoring

* Different types can be designed as per electrical systematic drawing.

Ordering References

Standard ordering:

      ZXF8030- BADK

      B-/…(refer to P222 ）

      A-()/ …（refer to P 224）

      D-()/…（refer to P225)

      K-/…（refer to P226)

Technical Parameters

Compliance with:

      GB 3836.1, GB 3836.2, GB 3836.3, GB 12476.1, GB12476.5

      IEC60079-0, IEC60079-1, IEC60079-7, IEC61241-0, IEC 61241-1

Explosion protection:

      Ex d e IICT6 Gb

      Ex tD A21 IP65 T80℃

Rated voltage: AC 220/380V

Rated current: 10A

Using sorts: AC-13 DC-15

Ingress protection: IP65

Corrosion resistance: WF2

Types: Control unit

Cable entries: G3/4″

Cable outer diameters: Φ9mm~Φ14;

Types: Electrical hoist button

Cable entries: G1″

Cable outer diameters: Φ11 mm ~Φ18 mm.
